Safety measures and handling of the device

• Handle carefully. Avoid dropping the device.
• Keep the NerdQAxe++ away from water and excessive heat and make sure you operate it in a well ventilated area.
• Ensure you use the correct power input.
  • Only use the 12V 10A power supply provided by Power mining. We have tested its compatibility with this device. Using third-party power supplies may lead to damage or safety risk.
• Connecting multiple high-power devices to one outlet can trip breakers or cause a fire hazard.
• Always disconnect the power before carrying out any maintenance or adjustments.
• We provide warranty service for the devices in the EU market according to EU market regulations, while in the rest of the world 90 days. If you need any assistance, please contact support@powermining.io
• Don't open the casing or modify the internals unless directed. This voids warranty.
• Unplug immediately if you see smoke or smell burning. Never use water on electrical fires.
• Follow local waste regulation rules. Recycle parts when possible.

Setup

Attach the stand by using 6 provided M3x5mm bolts and hex wrench to attach the stand to the board through the holes.

Attach the provided C13 cable to the 12V 10A PSU and plug in the DC jack.

Use either 📱phone or 💻 computer to find the temporary setup Wi-Fi SSID Nerdaxe_**** and connect to it.

Press “Settings” section.

• Enter Wi-Fi name (SSID) & password and click save;
• Under Primary Stratum Pool enter your Bitcoin address followed by .nerdqaxe;

• Scroll down to check if NerdQAxe++ has the latest version* and click save;
• Lastly restart the device to enact changes.

FAQ

What is the main difference between Bitaxe Gamma and NerdQaxe++?

Bitaxe Gamma is a 5V open-source Bitcoin miner with 1 ASIC chip and achieves ~1.1 TH/s hashrate while consuming ~18W of electricity. At an energy price of $0.20 per kWh, it will cost ~2.5 per month in electricity. Bitaxe has one color OLED display with ESP32 chip on the board.

NerdQaxe++ is a 12V open-source Bitcoin miner with 4 ASIC chips and achieves ~4.8 TH/s hashrate while consuming ~80W of electricity. At an energy price of $0.20 per kWh, it will cost ~$11.5 per month in electricity. NerdQaxe++ has a LilyGo T-Display-S3 LCD display with a built-in ESP32 chip.

How much can I make with these devices?

Disclaimer: both Bitaxe Gamma and NerdQaxe++ are more like hobby devices so do not expect financial returns on these.

The default mining mode is solo mining. That means you either get 3.125 BTC to the set BTC address or nothing. You check the probabilities for finding a Bitcoin block here.

To mine with regular payouts we suggest making an account with pool.braiins.com as they support Lightning Network for Bitcoin transactions with low fees. You can use their profitability calculator to get an understanding on how much you can mine with these.

What is the point of owning a home miner like Bitaxe or NerdQaxe++?

By owning and running a home miner such as Bitaxe or NerdQaxe++ you can learn about Bitcoin mining while decentralizing the hashrate. Miners like Bitaxe and NerdQaxe++ are fully open-source technology which is ideal for education and experimentation with active community support and continuous updates and firmware improvements.

Technical FAQ

How can I access the dashboard?

Check the screen of your Bitaxe & NerdQaxe++. There will be an IP address (such as 192.168.18.21) displayed if it is connected to the WiFi successfully. Enter this IP address in the Internet browser (such as Google Chrome, Firefox, Brave etc). Make sure to be connected to the same WiFi network as your miner. Try with other browsers if one does not open up the dashboard.

What to do if my miner is not connecting to the WiFi?

You can try the following things:

• Check if the name (WiFi SSID) and password is correct.

• Disable VPN if you have one.

• Try connecting to a phone hotspot to check if it works (if you are using iPhone, please enable “Maximise Compatibility" under Personal Hotspot settings).

What if my miner is connected to the WiFi, but not hashing?

If your device is connected to the WiFi and you can access the dashboard please double check if your pool settings are correct (Stratum Host & Stratum Port). Make sure to copy the Bitcoin address (Stratum User) without any mistakes. If any of these settings are incorrect, the device will not mine.

What if my NerdQaxe++ overheats?

NerdQaxe++ most often overheats due to hot voltage regulators. You can move the fan slightly upwards so more air blows past the heatsink onto voltage regulators. It is also possible to attach an additional fan to cool the voltage regulator area.

What if something is wrong with NerdQaxe++, but I don't know what?

You can try to reflash (reset) the device using NerdQaxe++ webflasher:

1. Connect NerdQaxe++ using USBC cable (probably named USB JTAG/...)
2. Select device - NerdQaxe++ (4x BM1370)
3. Select firmware version - latest
4. Start flashing
